External 箱外

Weights 重量

Length长度

Width宽度

Height高度

Max Gross Weight最大总重

Tare Weight

自重

Max Payload

最大载重

12,192 mm

2,438 mm

2,896 mm

10,000 Kg

4,360 Kg

5,640 Kg

40’

8’

9’6”

22,050 Lbs

9,610 Lbs

12,440 Lbs

Internal 箱内

Door   Opening 开门尺寸

Length 长度

Width 宽度

Height 高度

Width 宽度

Height 高度

11,903 mm

2,290 mm

2,591 mm

2,294 mm

2,569 mm

39’ 5/8”

7’-6 5/32”

8’-6 1/64”

7’-6 5/16”

8’-5 9/64”

Allowable   Stacking Weight 允许堆码重量

Cubic   Capacity 容积

216,000   Kg

476,200   Lbs

70.6 M³

2,500 FT³

Special   Feature 特点

The left   and right inner panels are equipped with a number of axle seats, which can be   combined with other equipment to grow vegetables and fruits.

左右内侧板安装有若干轴座，与其他设备组合后可种植蔬菜水果。

The top   plate has 15 chutes for mounting lights, and is evenly distributed.

顶板有可安装灯的滑槽15条，前后均布。

The front   end is single-opened, and the other side can be equipped with a motor and   other equipment.

前端单开门，另一边安装电机等设备。
